Quick Details

  • Condition: New
  • Type: Vacuum Forming Machine
  • Plastic Type: ABS
  • Product Type: Blister
  • Automatic: Yes
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Junsai
  • Model Number: HSD1814
  • Voltage: 380V 50HZ Customizable
  • Power(W): APP75KW
  • Weight: 4000KG
  • Dimension(L*W*H): 2800X2100X2400mm
  • Certification: ISO CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Suitable material: PP.PS.PE.PVC.PET.ABS.PC.HDPE
  • Application: automotive trim,roof-box,luggage,car bumper,bathtub,plates
  • Max Forming Area: 1800*1400mm
  • Material Thickness: 1-12mm
  • Max Height Of Mold: 500mm
  • Work efficiency: 1-5 mold/min
  • Warranty: 1 Year,lifelong service
  • PLC+Touch screen: Yes
  • Servo Motor: Yes
  • Product name: Customized ABS plastic product vacuum forming machine

Packaging & Delivery

Packaging Details Wrapped with plastic film & tarpaulin, loaded in 40HQ or 40FR.
Customized ABS plastic product vacuum forming machine.
Delivery Time Shipped in 45 day, ABS plastic product vacuum forming machine

ABS plastic product vacuum forming machine

Product Description

              Full automatic thick sheet plastic vacuum forming machine is our research and manufacturing of a new type of automatic thick sheet vacuum forming machine.Which adopts the world's most advanced technology and the latest German technology.It's suitable for plastic products with low processing precision.The equipment and molds are cheap and easy operate, thereby greatly improving the production efficiency. Equipment, mechanical, electrical, pneumatic design, the use of programmable logic controller (PLC) control, human-machine interface operation, near (far) infrared heating, to achieve local temperature adjustable according to the size and shape of the molding, 30% energy saving than the previous plastic machine.







  ABS plastic product vacuum forming machine

Product configuration

Max forming area1500*1200mm   Customizable
Max mould height500mm   Customizable
Material Thickness1-12mm
Applied MaterialsABS,PS,PE,PP,PC,PVC,PMMA etc
Work efficiency1-5 mold/ min
Voltage380V/50HZ   customizable
Vacuum Pump150m3/h
Air Pressure0.6-0.8Mpa
Industrial Chiller6 HP
Temperature control systemYes
PLC control+Servo motorYes
Touch Screen15 inch colorized touch screen



ABS plastic product vacuum forming machine

Machine core parts

All of our machine's core parts are made in China's best or purchased from developed manufacturing countries such as Germany, UK, France, japan,China Taiwan, etc.. So as to ensure the quality of products to achieve the best,It is the other suppliers can not provide.

"Our Professional,Your Advantage



Part NameBrandOriginalQuantity
Vacuum PumpRietschle Germany1 set
Spray GunMeiji Japan4 pcs
Control RelayOmronJapan 21 pcs
Pull Sheet Servo MotorDelta Taiwan,China2 set
Electromagnetic valveSMC Japan 2 pcs
AC contactorSchneiderFrence 2 pcs
PLCDeltaTaiwan,China1 set
Touch ScreenDeltaTaiwan,China1 set
Water FilterNorgrenUK1 pcs
MotorTVTTaiwan,China3 set



ABS plastic product vacuum forming machine

Product Application                                             Applicable to 1-12 mm of ABS,Acrylic PS, PE, PC, PP, PVC, plastic sheet vacuum thermoforming .The machine can produce automatic interior trim,car bumper ,fender, mats;luggage case,roof box , refrigerator liner,bathtubs,filter plates,trays and other plastic products.





  ABS plastic product vacuum forming machine

Main Features



  • Machine structure

            It consists of plate positioning system, plastic mold positioning system, frame system, heating system, cooling system and electrical control system.

  • Technological process

           Feeding material  heating softening Pre-strechforming cooling stereotypes stripping,Proceed to the next cycle.



  ABS plastic product vacuum forming machine

Our company



About

DongguanJungjingsai Packaging Machinery Co.,Ltd.Is a collection research and design, manufacture,sales and service as one of the professional plastic machinery manufacture brand-name enterprises.

Specializing in the manufacture of vacuum forming machine, plastic thermoforming machine.Has more than 10 years of production experience, advanced technology in China in a leading position, excellent product quality and cheap.Suitable for 0.1-12mm ABS,PS,PE,PC,PP,PVC and other thermoplastic materials thermoforming,can be produced automatic interior trim,refrigerator liner,bathtubs,filter plates,trays and other plastic products.



ABS plastic product vacuum forming machine

Our Advantage

  • Advanced Technology

            More than ten years of production experience, advanced technology, rich experience, excellent product performance.More experience, more mature products, Better quality products.

  • Excellent machine parts

          Our machines are all made of the best parts, and all the core parts are imported from other industrial developed countries, such as Germany, Britain, France, Japan and Taiwan. to ensure the quality of the product to achieve the best.

  • More energy-efficient

         According to the size and shape of the forming area to achieve local temperature adjustable, energy saving than other plastic machine 30%.More energy conservation and environmental protection.

ABS plastic product vacuum forming machine

FAQ



FAQ

01

What kind of products can be produced by this machine?

It’s Applicable to 1-12 mm of ABS,Acrylic PS, PE, PC, PP, PVC, plastic sheet vacuum thermoforming. The machine to produce automatic interior trim,refrigerator liner,bathtubs,filter plates,trays and other plastic products.



02

What kind of plastic is applied to?

This product can be used for processing all kinds of thermoplastic thin sheet, such as ABS, PP, PE, PS, PC, PVC, EPS, HIPS, HDPE, PMMA, PET, PETG and other thermoplastic materials.



03

What about your quality assurance and after-sales service?

We ensure that each equipment delivered to the customer is the best quality through the test, in addition to our product warranty for one year, the replacement of spare parts, we will provide you with a lifetime service.



04

What if we buy your product and can't operate the machine?

Our products are very simple to operate, as well as detailed instructions, operating video, and overseas engineers to guide the operation, know that you have learned so far.



05

I want to see your machine,where is your factory?

Our company is located in Guangdong, Dongguan province. It is between Guangzhou and Shenzhen. You can take a plane to one of these airports and we will pick you up.



06

Can your machine be customized?

Yes, we will tailor a machine for you according to the product you want to make. Of course, we also have some machines on the ready-made specifications to meet your needs.



ABS plastic product vacuum forming machine

Packaging and Delivery

PACKAGE:

The normal package is wrapped with stretch film or wooden crates packing(charge),loaded in 40FR.

DELIVERY TIME:

45 days after paying deposit,detail delivery date should be decided according to customer needs.

ABS plastic product vacuum forming machine

Contact Us

TEL:+86-15767350770
WhatsApp:+86-15767350770

www.pudi-china.com

ADD: Buxiang Industrial Zone,
Hengli Town, Dongguan City,
Guangdong Province, China(Mainland)
